1.28kWh lithium battery for compact backup power
The Esener 1.28kWh lithium battery provides 100Ah of storage at a nominal 12.8V for small backup and solar power systems. Its battery management system provides current limiting and protection against overcharging, over-discharging and excessive temperature.
Wall or shelf mounting gives you a choice of installation positions, while low self-discharge helps retain stored energy between uses. USB and 12V DC outputs provide connections for suitable devices, alongside the AC output. Series and parallel expansion supports a maximum 2S2P configuration. For an external inverter or charger, use equipment suitable for the battery's voltage, charging requirements and current limits.
The battery-level indicator is approximate and must not be used as a precise measurement of remaining capacity.
Features
- 100Ah storage: Provides 1.28kWh of nominal energy storage at 12.8V.
- 1C performance: Supports 1C charging and discharging, with a maximum continuous discharge current of 100A.
- Battery protection: Includes current limiting and protection against overcharging, over-discharging and excessive temperature.
- Series and parallel expansion: Supports configurations up to 2S2P.
- Flexible installation: Supports wall or shelf mounting.
- Multiple output connections: Includes USB, 12V DC and AC outputs for suitable connected equipment.
- Low self-discharge: Helps retain stored energy between uses.
Specifications
- Nominal energy storage: 1.28kWh
- Nominal capacity at 1C: 100Ah
- Nominal voltage: 12.8V
- Discharge cut-off voltage: 11.5V
- Equalised charge voltage: 14.6V
- Float voltage: 13.5V
- Bulk voltage: 13.8–14.2V
- Maximum continuous charging current: 100A
- Maximum continuous discharging current: 100A
- Pulse current: 120A for 5 seconds
- C rating: 1C
- Battery-level indicator: Approximate only; not a precise capacity measurement
- Series and parallel connection: Maximum 2S2P
- Ports: 2 x parallel instruction ports
- Cells: New lithium-ion cylindrical cells
- Battery chemistry: Lithium iron phosphate (LiFePO4)
- Design life: Approximately 15 years
- Cycle life at 1C: Approximately 5000 cycles at 80% depth of discharge
- External charging equipment: Suitable 12V inverter, lithium battery charger or solar charge controller
- Outputs:
- USB: 5V/1A and 5V/2.1A
- Cigarette-lighter output: 12V/2–8A
- Light output: 12V/120W/10A
- AC output: 220V/300W
- Operating temperatures:
- Charging: 0°C to 50°C
- Discharging: -10°C to 50°C
- Storage: -10°C to 50°C
- Protection:
- Electronic circuit breaker
- Battery management voltage protection
- Current limiting
- Overcharge, over-discharge and over-temperature protection
- Ingress protection: IP55
- Warranty: 5 years
- Dimensions (L x W x H): 300 x 380 x 152mm
- Weight: 14.1kg
- User manual: Download user manual (PDF)
What's in the box
What's in the box
Warranty
Warranty
5 Years
FAQ
FAQ
What is 1.28kWh Multifunctional Lithium Battery 12.8V and what does it do?
1.28kWh Multifunctional Lithium Battery 12.8V is a compact energy storage solution that provides 100Ah of power at a nominal voltage of 12.8V, making it ideal for backup and solar power systems, with multiple output connections including USB and AC. It features a battery management system for protection against overcharging and excessive temperatures, and supports configurations up to 2S2P for expansion.
What are the key features of 1.28kWh Multifunctional Lithium Battery 12.8V?
The 1.28kWh Multifunctional Lithium Battery 12.8V offers 100Ah of storage at a nominal voltage of 12.8V, supports a maximum continuous discharge current of 100A, and features multiple output connections including USB and AC outputs. It also includes a battery management system for protection against overcharging and excessive temperatures, and can be installed on a wall or shelf.
How do I use 1.28kWh Multifunctional Lithium Battery 12.8V?
To use the 1.28kWh Multifunctional Lithium Battery 12.8V, connect it to suitable external charging equipment like a 12V inverter or solar charge controller, and utilize its USB, 12V DC, or AC outputs for your devices, ensuring to follow the installation guidelines for wall or shelf mounting.
What sizes or variants are available for 1.28kWh Multifunctional Lithium Battery 12.8V?
The 1.28kWh Multifunctional Lithium Battery 12.8V is available in a single configuration with a nominal capacity of 100Ah and dimensions of 300 x 380 x 152mm.
What is included in the box with 1.28kWh Multifunctional Lithium Battery 12.8V?
The box includes the 1.28kWh Multifunctional Lithium Battery 12.8V and a user manual for guidance on installation and usage.
