Hikvision Network PT Security Camera 4mm Lens 2MP

2MP resolution (1920 × 1080) for sharp, clear video
EXIR 2.0 Infrared Technology provides enhanced night vision with a 30m IR range
Supports Wi-Fi connectivity
H.265 Video Compression: Saves storage space while maintaining video quality
Two-way audio for real-time communication
Ip66-rated dust and water-resistant for outdoor and indoor use
Motion Detection & Alerts in real-time
MicroSD card slot supports up to 512GB for local video storage
Compatible with Hik-Connect, iVMS-4200, and major security platforms

Camera:
Image Sensor: 1/3" Progressive Scan CMOS
Max. Resolution: 1920 × 1080 (2 MP)
Min. Illumination: Colour: 0.005 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR
Shutter Time: 1/3s to 1/10000s
Day & Night: IR cut filter
Angle Adjustment: Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360°
Lens:
Lens Type: Fixed focal lens, 4mm
Focal Length & FOV:4mm: Horizontal FOV 75°, Vertical FOV 45°, Diagonal FOV 85°
Aperture: F2.0
Lens Mount: M12
Illuminator:
Supplement Light Type: IR
IR Wavelength: 850nm
Supplement Light Range: Up to 10m
Video:
Main Stream: 50Hz: 25 fps (1920 × 1080, 1280 × 720, 768 × 432) 60Hz: 30 fps (1920 × 1080, 1280 × 720, 768 × 432)
Sub-Stream: 50Hz: 50Hz: 25 fps (768 × 432, 512 × 288) 60Hz: 30 fps (768 × 432, 512 × 288)
Video Compression: Main Stream: Main stream: H.265/H.264 Sub-stream: H.265/H.264
Video Bit Rate: Up to 1Mbps
Frame Rate: Max.15 fps - Self-Adaptive during network transmission
Audio:
Audio Compression: G.711/AAC-LC
Audio Bit Rate: 64 Kbps (G.711ulaw/G.711alaw)/16 to 64 Kbps (AAC-LC)
Audio Sampling Rate: 8 kHz/16kHz
Environment Noise Filtering: Yes
Network:
Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, UPnP, IGMP, QoS, IPv4, UDP, Bonjour, SSL/TLS
Simultaneous Live View: Up to 4 channels
API: ONVIF (Profile S, Profile T, Profile G), SDK
User/Host: Administrator
Security: Password protection, HTTPS encryption, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE for Open Network Video Interface
Client: iVMS-4200, Hik-Connect, Hik-Partner-Pro
Wi-Fi:
Transfer Rate: 11b: up to 54Mbps, 11g: up to 54Mbps, 11n: up to 150 Mbps
Encryption Mode: WPA-PSK/WPA2-PSK
Frequency Range: 2.412GHz to 2.472GHz
Channel Bandwidth: 20MHz
Wireless Range: Up to 50m (performance varies based on environment)
Image:
Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software
Day/Night Switch: Auto
Wide Dynamic Range (WDR): Digital WDR
Privacy Mask: 4 programmable polygon privacy masks
Interface:
Built-in Microphone: Yes
Built-in Speaker: Yes
On-Board Storage: Built-in memory card slot, support microSD card, up to 512GB
Reset Key: Yes
Ethernet Interface: 1 RJ45 10M/100M self-adaptive Ethernet port
General:
Material: Plastic
Power: 5 VDC ± 10%, 1A, max. 5W
Storage Conditions: -10 °C to 45 °C (14 °F to 113 °F). Humidity 95% or less (non-condensing)
Startup & Operating Conditions: -10°C to 45°C (14°F to 113°F). Humidity 95% or less (non-condensing)
General Function: Heartbeat, mirror
Flashing Light: Red and Blue
Dimension: Ø 8 × 12.2 cm
Weight: Approx. 216 g
Protection: IP66

Hikvision Network PT Security Camera, 4mm Lens, 2MP x1
User Manual x1

12 Months
