Growtech Axpert GT 6.2kW Inverter
Growtech Axpert GT 6.2kW Inverter
- Delivery: 4 - 7 working days
Low stock: only 5 left
Couldn't load pickup availability
Share
The Growtech Axpert GT 6.2kW Inverter boasts exceptional performance and value, making it a top choice among competitors. Despite its competitive price, this inverter offers advanced capabilities, such as a Lithium activation feature that can recover batteries from protection mode after over-discharge, ensuring continuous energy storage and usage. With 6.3kW of output in pure sine wave, a 120A MPPT controller that supports up to 6500W of PV array power, and a higher solar input current of 27A, this inverter provides efficient energy management for both residential and small commercial applications. Optional Wi-Fi connectivity adds convenience, enabling remote monitoring.
Features
Features
Pure Sine Wave Output: Provides stable, clean energy for all electrical loads
Lithium Activation Function: Revives batteries from protection mode
Built-in MPPT Controller: Supports up to 6500W of PV array power for optimized solar energy conversion
High Solar Input Current: 27A, enabling the connection of more solar panels for increased energy generation
Optional WiFi Connectivity: Enables remote monitoring and management for added convenience
Standard LCD Display: Offers clear and essential information for system monitoring and settings
Compact Design: Space-saving and easy to install, ideal for smaller setups
Protection Features: Safeguards against overload, short circuit, and deep discharge
Specifications
Specifications
Capacity: 6.2kVA/6.2kW
Parallel Capability: No
Lithium Battery Activation: PV & Utility
Input:
Nominal Voltage: 230V AC
Acceptable Voltage Range: 170~280V (for PC)/90~280V AC (for home appliances)
Frequency: 50Hz/60Hz (auto sensing)
Output:
Nominal Voltage: 220/230V AC ±5%
Rated Power: 6.2kVA/6.2kW
Surge Power: 12400W
Waveform: Pure Sine Wave
Frequency: 50/60Hz
Transfer Time: 10ms(for PC)/20ms (for home appliances)
Peak Efficiency (PV to inverter): 96%
Peak Efficiency (battery to inverter): 93%
Overload Protection: 5s@ ≥140% load; 10s@100-140% load
Crest Factor: 3:1
Admissible Power Factor: 0.6~1 (inductive or capacitive)
Battery:
Battery Voltage: 48V DC
Floating Charge Voltage: 54V DC
Overcharge Protection: 63V DC
Charging Method: CC/CV
Solar Charger & AC Charger:
Solar Charger Type: MPPT
Maximum PV Array Power: 6500W
Maximum PV Array Open Circuit Voltage: 500V DC
PV Array MPPT Voltage Range: 60~500V DC
PV Max Input Current: 27A
Maximum Solar Charge Current: 120A
Maximum AC Charge Current: 80A
Maximum Charge Current: 120A
Communication Interface: RS232 = RS485
Humidity: 5% to 95% relative humidity (non-condensing)
Operating Temperature Range: -10°C to 50°C
Storage Temperature: -15°C to 50°C
Dimensions: 428 x 295 x 105mm
Weight: 9kg
What's in the box
What's in the box
Growtech Axpert GT 6.2kW Inverter
Warranty
Warranty
1 year
